Yukon

Vertical form, fill and seal machine, model YUKON PE with centre folded film
controlled by PLC Siemens.
General technical characteristics:
– Main Structure made of painted steel;
– Electrical cabinet is fixed to the machine;
– Pneumatic reel-holder shaft;
– End of film automatic detection;
– Motorized film-pulling unit;
– Film-unwind process is carried out by toothed belts;
– N.1 Loading station;
– Pneumatic unit for horizontal sealing and cutting, with sealing wire and knife;
– Pneumatic unit for vertical sealing and cutting processes, by a hot bar;
– Bag length measuring system: Encoder;
– Exit belt incorporated;
– Film pulling device for wasted film;
– Max. bag heigth: 500mm;
– Max. empty bag width: 480 mm;
– Max film reel height: 570mm.
– PLC Siemens control system;
– CE Certification.
– Power Supply: 380V-50HZ-3 phase+N-Ground.
